42"-DIA. EXHAUST FAN, HEAVY DUTY BELT DRIVE (LESS DRIVE PACKAGE)
EXHAUST FAN,TYPE: HEAVY DUTY BELT DRIVE LESS DRIVE PACKAGE , CFM RANGE: 20,652 TO 30,825, EXHAUST/SUPPLY FAN MOTOR HP: 1 TO 5, MAX AMBIENT TEMP: 104* F, RPM RANGE: 605 TO 903, BEARING TYPE: REGREASABLE CAST PILLOW BLOCK, MOUNTING POSITION: HORIZONTAL OR VERTICAL, FRAME MATERIAL: GALVANIZED STEEL, PROPELLER MATERIAL: CAST ALUMINUM, NUMBER OF BLADES: 6, BEARING AND SHAFT SIZE: 1 1/2", FLANGE DEPTH: 2", BLADE DIAMETER: 42", HEIGHT: 46", WIDTH: 46", MAX DEPTH: 26 3/8", VENTURI CLEARANCE DIAMETER: 42 1/2", VENTURI DEPTH: 6", WEIGHT: 235 LBS, MADE IN MEXICO. REQUIRES: WALL COLLAR AND SHUTTER FOR NEW INSTALLATION.
Original: $700.00
-65%$700.00
$245.00
Description
EXHAUST FAN,TYPE: HEAVY DUTY BELT DRIVE LESS DRIVE PACKAGE , CFM RANGE: 20,652 TO 30,825, EXHAUST/SUPPLY FAN MOTOR HP: 1 TO 5, MAX AMBIENT TEMP: 104* F, RPM RANGE: 605 TO 903, BEARING TYPE: REGREASABLE CAST PILLOW BLOCK, MOUNTING POSITION: HORIZONTAL OR VERTICAL, FRAME MATERIAL: GALVANIZED STEEL, PROPELLER MATERIAL: CAST ALUMINUM, NUMBER OF BLADES: 6, BEARING AND SHAFT SIZE: 1 1/2", FLANGE DEPTH: 2", BLADE DIAMETER: 42", HEIGHT: 46", WIDTH: 46", MAX DEPTH: 26 3/8", VENTURI CLEARANCE DIAMETER: 42 1/2", VENTURI DEPTH: 6", WEIGHT: 235 LBS, MADE IN MEXICO. REQUIRES: WALL COLLAR AND SHUTTER FOR NEW INSTALLATION.
